Chipset Sigma Designs SMP8643, 667MHz CPU with floating point coprocessor. DRM Cardea DRM (WMDRM-ND) Janus DRM (WMDRM-PD) Memory 512MB DDR2 DRAM, 256MB NAND Flash Audio/Video Outputs HDMI v1.3a, 36bpp deep color, 12-bit xvYCC processing and HDCP 1.2 content protection Component Video S-Video Composite Video Stereo Analog Audio S/PDIF Optical and Coaxial Digital Audio Other Interface Power LED and Attention LED 1x USB 2.0 host at the front 1x USB 2.0 host at the back 1x USB 2.0 slave at the back Internal mounting for 2.5" or 3.5" SATA HDD Infra-Red Remote Control Full power down, standby and power up by remote control Service pin hole for TV Mode switching and shutting down without remote control Special designed fan that generate very low noise Speed: 3800RPM (typical) ± 10% Noise Level: 18.5 dB(A) Size: L * W * H =62*62*15(mm) Network Ethernet 10/100/1000** Mbps **Gigabit support depends on Switch/Router compatibility Supported Media File Formats Video containers: MPEG1/2/4 Elementary (M1V, M2V, M4V) MPEG1/2 PS (M2P, MPG, DAT, VOB) MPEG2 Transport Stream (TS, TP, TRP, M2T, M2TS, MTS) AVI, ASF, WMV Matroska (MKV) MOV (H.264), MP4, RMP4
Video Decoders: XVID SD/HD MPEG-1 MPEG-2 MP@HL MPEG-4.2 ASP@L5, 720p, 1-point GMC MPEG-4.10 (H.264) : BP@L3, MP@L4.0, HP@L4.0, HP@L4.1 WMV9 : MP@HL SMPTE 421M (VC-1) : MP@HL, AP@L3
Audio Containers: AAC, M4A MPEG audio (MP1, MP2, MP3, MPA) WAV WMA FLAC OGG
Audio Decoders: Dolby Digital DTS WMA, WMA Pro MPEG-1 Layer 1, 2, 3 MPEG-4 AAC-LC MPEG-4 HE-AAC MPEG-4 BSAC LPCM FLAC Vorbis
|
Audio Pass-Through: DTS, DTS-HD HR, DTS-HD MA Dolby Digital, Dolby Digital Plus, Dolby True HD
Other Formats: ISO, IFO navigation AVCHD navigation Simple BD navigation
Photo Formats: JPEG, BMP, PNG, GIF
Subtitle Formats: SRT, MicroDVD SUB, SSA, SUB/IDX
Connectivity Bonjour UPnP SSDP UPnP AV Windows Media Connect Windows Media Player NSS Samba NFS
Media Servers: myiHome, myiHomeLite, myiHomeMS (UPnP), MSP Portal Third-party media servers: WizD, SwissCenter, Llink, GB-PVR
BitTorrent P2P Usenet downloader
NAS Access : SMB, NFS, FTP
Casgle iDVR RSS feed downloader
Web Services Video : Revision 3, Videocast, CNET TV, Mediafly, Mevio, Bliptv, Break Podcast, CBS Evening News, CNN Anderson Cooper 360 Daily, CNN The Larry King Podcast, NBC Today Show, The CNN Daily, CNN In Case You Missed It, NBC Nightly News, NBC Meet The Press, CBS Face the Nation, Podfinder UK, Motorz
Audio : Jamendo, iPodcast, BBC Podcast, Indiefeed, CNN News, ABC News
Photos : Flickr, Picasaweb, Pikeo, 23, Photobucket, SmugMug
RSS feed : Yahoo! Weather, NMT Forum, Bloglines, Cinecast, MSNBC News, Traffice Condition, Yahoo! Traffic Alerts, Yahoo! News, Weather Bug
Peer-to-peer TV : SayaTV
Internet Radio : SHOUTCast™ Radio, Radiobox, Live365 Radio
Power AC-DC adaptor Input 100~240V AC, 50~60 Hz Output 12V DC, 3A max typical : 8 W (no additional device installed/attached) maximum : 36 W Footprint Width x Depth x Height : 270mm x 150mm x 50mm (10.63" x 5.90" x 1.97") Weight 1.6kg (3.5lbs) Dolby Digital: "Dolby" and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license from Dolby Laboratories.
|
