Maximum Printing Resolution |
4800 (horizontal)*1 x 1200 (vertical) dpi |
Print Head / Ink |
Type / Ink System: |
FINE Cartridge |
Total Number of Nozzles: |
1,472 nozzles |
Min. Ink Droplet Size: |
2pl |
Ink Tank: |
PG-810, CL-811 (PG-810XL, CL-811XL Optional) |
Print Speed Based on ISO / IEC 24734. Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions |
Document: Colour*2: ESAT / Simplex: |
Approx. 5.0ipm |
Document: B/W*2: ESAT / Simplex: |
Approx. 8.7ipm |
Photo (4 x 6")*2: PP-201 / Standard / Borderless: |
Approx. 42secs. |
Printable Width |
Up to 203.2mm (8-inch) |
Borderless: |
Up to 216mm (8.5-inch) |
Recommended Printing Area |
Top margin: |
31.2mm |
Bottom margin: |
32.5mm |
Paper Size*3 |
A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", 8 x 10", Envelopes (DL, COM10) |
|
|
Scanner Type |
Flatbed & ADF |
Scanning Method |
CIS |
Optical Resolution*4 |
1200 x 2400dpi |
Selectable Resolution |
25 - 19200dpi |
Scanning Bit Depth (Input / Output) |
Grayscale: |
16 / 8 bits |
Colour: |
48 / 24 bits (RGB each 16 / 8 bits) |
Line Scanning Speed*5 |
Grayscale: |
1.1ms/line (300dpi) |
Colour: |
3.4ms/line (300dpi) |
Scanning Speed*6 |
Reflective: A4 Colour / 300dpi: |
Approx. 14secs. |
Maximum Document Size |
Flatbed: |
A4, LTR (216 x 297mm) |
ADF: |
A4, LTR, LGL |
|
|
Image Quality |
3 positions (Fast, Standard, High) |
Density Adjustment |
9 positions, Auto intensity (AE copy)* * Not supported for ADF |
Copy Speed*7 Based on ISO / IEC 24735 and ISO / IEC 29183 standards. Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions |
Document: Colour: sFCOT / Simplex: |
Approx. 23secs. |
Document: Colour: sESAT / Simplex: |
Approx. 4.0ipm |
Document (ADF): Colour: ESAT / Simplex: |
Approx. 3.4ipm |
Multiple Copy |
Black / Colour: |
Max. 99 pages |
|
|
Type |
Desktop Transceiver (Super G3 / Colour Communication) |
Applicable Line |
PSTN (Public Switched Telephone Network) |
Transmission Speed*8 |
Black: |
Approx. 3secs. (33.6kbps) |
Colour: |
Approx. 1min. (33.6kbps) |
Fax Resolution |
Black: |
8pels/mm x 3.85lines/mm (Standard), 8pels/mm x 7.7lines/mm (Fine), 300 x 300dpi (Extra Fine) |
Colour: |
200 x 200dpi |
Print Size |
A4, LTR, LGL |
Scanning Width |
208mm (A4), 214mm (LTR) |
Modem Speed |
Max. 33.6kbps (Automatic fall back) |
Compression |
Black: |
MH, MR, MMR |
Colour: |
JPEG |
Gradation |
Black: |
256 levels |
Colour: |
24 bits Full colour (RGB each 8 bits) |
ECM (Error Correction Mode) |
ITU-T T.30 compatible |
Automatic Dialing |
Coded Speed Dialing: |
Max. 20 locations |
Group Dialing: |
Max. 19 locations |
Transmission / Reception Memory*9 |
Approx. 50 pages |
|
|
Type |
Windows: |
via FAX modem (in MFP) |
Mac: |
N/A |
Destination Number |
1 location |
Black / Colour |
B/W transmission only |
|
|
Protocol |
TCP/IP |
Wired LAN |
Network Type: |
IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T) |
Data Rate: |
100M / 10Mbps (auto switchable) |
Wireless LAN |
Network Type: |
IEEE802.11n / IEEE802.11g / IEEE802.11b |
Frequency Band: |
2.4GHz |
Channel*10: |
1 - 13 |
Data Rate: |
IEEE802.11n: Max.150Mbps IEEE802.11g: Max. 54Mbps IEEE802.11b: Max. 11Mbps |
Range: |
indoor 50m (depends on the transmission speed and conditions) |
Security: |
WEP64 / 128 bits, WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES) |
|
|
Rear Tray (Maximum Number) |
Plain Paper |
A4, A5, B5, LTR = 100, LGL = 10 |
High Resolution Paper (HR-101N) |
A4 = 80 |
Photo Paper Pro Platinum (PT-101) |
4 x 6" = 20, A4, 8 x 10" = 10 |
Photo Paper Plus Glossy II (PP-201) |
4 x 6" = 20, A4 = 10 |
Photo Paper Plus Semi-Gloss (SG-201) |
4 x 6" = 20, A4 = 10 |
Glossy Photo Paper "Everyday Use" (GP-501) |
4 x 6" = 20, A4 = 10 |
Matte Photo Paper (MP-101) |
4 x 6" = 20, A4 = 10 |
Photo Stickers (PS-101) |
1 |
T-Shirt Transfer (TR-301) |
1 |
Envelope |
European DL, US Com. #10 = 10 |
Auto Document Feeder (ADF) |
Paper Handling (Plain Paper): |
A4, LTR = 30, LGL = 5 |
|
|
Rear Tray |
Plain Paper: |
64 - 105g/m2 |
Canon Specialty Paper: Max. Paper Weight: |
Approx. 300g/m2 (Photo Paper Pro Platinum PT-101) |
|
|
Windows*12 |
Windows XP, Windows Vista, Windows 7 |
Macintosh*12 |
Macintosh OS X 10.4.11 - 10.6 |
|
|
Card Direct |
Compatible Memory Card Formats: |
Compact Flash, Microdrive, Memory Stick, Memory Stick PRO, SD Card, SDHC Card, MultiMedia Card, MultiMedia Card Plus, Memory Stick Duo, Memory Stick PRO Duo, xD-Picture Card*, xD-Picture Card Type M*, xD-Picture Card Type H*, Memory Stick Micro*, RS-MMC*, mini SD Card*, micro SD Card*, mini SDHC Card*, micro SDHC Card*, MMC mobile* * Can be used with the addition of a special adapter sold separately. |
File Formats: |
JPEG and TIFF (Exif-compliant) taken by DCF (Ver.1.0 / 2.0) compliant digital cameras. (Exif ver2.2 / 2.21 / 2.3 compliant)*11 |
PictBridge |
Compatible Digital Camera: |
"PictBridge" compliant digital cameras, camcorders and camera phones |
File Formats: |
JPEG (Exif ver2.2 / 2.21 / 2.3 compliant)*11 |
Scan to Memory |
Compatible Media: |
Memory Card, USB Flash Memory |
Direct Document Print |
PDF: |
Available |
|
|
Quick Start |
Approx. 3secs. |
Operation Panel |
Display: |
LCD (2.5-inch / 6.2cm TFT colour) |
Interface |
USB 2.0 Hi-Speed, PictBridge, Bluetooth v2.0 (Option): Maximum Speed 1.44Mbps (JPEG, PNG only, OPP, BIP) |
Card Slots |
Available |
Self-Opening Paper Output Tray |
Available |
Operating Environment |
Temperature: |
5 - 35°C |
Humidity: |
10 - 90% RH (no dew condensation) |
Storage Environment |
Temperature: |
0 - 40°C |
Humidity: |
5 - 95% RH (no dew condensation) |
Acoustic Noise (PC Print)*13 |
Approx. 45.2dB(A) |
Power |
AC 100 - 240V, 50 / 60Hz |
Power Consumption |
Standby (scanning lamp is off) (USB Connection to PC): |
Approx. 2.2W |
OFF (USB connection to PC): |
Approx. 0.3W |
Copying*14: |
Approx. 14W |
Environment |
Regulation: |
RoHS (EU, China), WEEE (EU) |
Eco-Label: |
Energy Star |
Duty Cycle |
Up to 3,000 pages/month |
Dimension (W x D x H) |
Approx. 458 x 415 x 198mm |
Weight |
Approx. 8.8kg |
